Wide LED Lighting for Acoustic Panels

Dimmable LED profile with COB LED strip (15W/m, IP20, 3000K, 1450lm, RA90, 24V).
Specially designed to replace a slat, providing a seamless integration with your acoustic panel. Includes 3 metres of cable.

⚠️ Note: Transformer and control system are not included. The profile is best mounted on site using adhesive.

Installation Guides:

• Guide for mounting LED strips (see installation manual).

• Guide for LED strip control

Installation Tips:

• Aluminium profile can be cut to the desired length with a standard hacksaw.

• LED strip can be cut with scissors at the marked intervals (every 5 cm).

• For rear cable exit, drill a hole at the back end of the aluminium profile and pull the cable through.

• For side cable exit, drill a hole in the end cap and feed the cable through.

• Ensure the LED strip adheres firmly. For extra hold, use a small amount of glue at the ends, especially near the cable, where pressure may lift the strip.
